INTRODUCTION
The Touch Screen allows users to operate the host as long as they lightly touch the icons or text on the computer display with their fingers, which eliminates keyboard and mouse operations and makes human-computer interaction more straightforward. Mainly used in public hall information query, leadership office, electronic games, song ordering, multimedia teaching, air ticket/train ticket pre-sale, etc. The products are mainly divided into three categories: capacitive touch screen, resistive touch screen and surface acoustic wave touch screen.
• Standard sizes List for PCAP touch overlay:
10.1”,10.4″,12.1″,13.3”,15″,15.6″,17″,17.3″,18.5”,19″,21.5″,22″,23″,23.6″,24″,27″,32″,42”,43”,49”,50”,55”,65”
FEATURES
♦ 100% brand new and high quality.
♦ Ultra thin ultra light design, easy to use, beautiful.
♦ High contrast, high brightness, greatly improve picture sense and show details better.
♦ Automatic elimination function to protect long-term use of LCD screen.
♦ Automatic adjustment function with images, support 16.7M colors, the picture is more natural, delicate.
♦ 8ms speed response time.
♦ Exquisite shell, shock proof, anti interference.
♦ Energy consumption is low, the LCD screen is more long life.
SPECIFICATION
LCD Screen Characteristics |
Size |
32 inches |
Resolution |
1920*1080/60Hz |
|
Display Scale |
16:9 |
|
Visual Angle |
89/89/89/89 (Typ.)(CR≥10) |
|
Contrast Ratio |
4000:1 |
|
Color Depth |
16.7M |
|
Response Time |
6.5 (Typ.) ms |
|
Brightness |
350 |
|
Signal |
LVDS |
|
Voltage |
12V |
|
Touch Screen |
Touch Tech |
Capacitive touch screen (G+G), optional ILITEK/EETI solution, optional AG cover, optional waterproof solution |
Points |
10 pt(requires system support) |
|
Touch Method |
Finger touch (active pen optional) |
|
Surface Hardness |
≥6H |
|
Response Time |
<3ms |
|
Transmittance |
≥85% |
|
Service life |
>50 million times |
|
Max Supported Resolution |
4096*4096 |
|
Linear Error |
≤2.5mm |
|
Haze |
3% (Max) |
|
Operating Temperature&Humidity |
-10~60℃, 20~85% RH,No condensation |
|
Storage Temperature & Humidity |
-20~70℃, 20~85% RH,No condensation |
|
Device |
Visual Area |
698.4(W)×392.85(H) mm |
Dimension |
770.7mm*465.6mm |
|
Monitor Height |
57.2mm |
|
All-in-one Height |
57.2mm |
|
Hole Size |
765mm*460.2mm R7.0 |
|
Display Interface |
VGA/DVI/HDMI optional |
|
Wall-mount Hole |
100mm*100mm |
